Cadillac V-Series.R
AERODYNAMICS

Cadillac V-Series.R

Surface modelling and geometry preparation project for CFD analysis of the Cadillac V-Series.R.

The project was developed in CATIA V5, with particular focus on surface modelling and the accurate reconstruction of the vehicle's exterior geometry. The model was built using Imagine & Shape and Generative Shape Design, with attention to the transitions between the different aerodynamic and bodywork elements.

Cadillac V-Series.R — detail 1Cadillac V-Series.R — detail 2Cadillac V-Series.R — detail 3Cadillac V-Series.R — detail 4Cadillac V-Series.R — detail 5Cadillac V-Series.R — detail 6Cadillac V-Series.R — detail 7
